Smeg KSEIV97X [9/12] Control panel
![Smeg KSEIV97X [9/12] Control panel](/views2/1015068/page9/bg9.png)
19GB
L
R
V1
V2
V3
M
S1 S2
USE
Control panel
L Light Switches the lighting system on and off.
S1 Led Motor running led.
It flashes once after 100 working hours of the hood to indicate that the grease
filters need washing.
It flashes twice after 200 working hours to indicate that the grease filters need
washing and that the anti-odour charcoal filters, if any, need changing.
S2 Led Intensive speed led.
M Motor Switches the extractor motor on and off at low speed. Used to provide a
contin-uos and silent air change in the presence of light cooking vapours.
When the Hood is in ELC (Electronic Comfort) mode, the button will not only
turn the Ducting motor on, but will also disable this function.
V1 Speed Reduces the operating speed.
When the button is pressed with the Motor off, ELC (Electronic Comfort)
mode will be enabled again, giving a continuous, low noise flow of air. Press
the button and hold it until Led S1 flashes slowly.
V2 Speed Increases the operating speed.
V3 Intensive Maximum speed, used for eliminating the highest cooking vapour emission.
Speed Switches off automatically after 10 minutes operation. Can also be switched
off manually by pressing the button.
R Receiver for Optional Remote Control.
Remote Control
