Technical Specifications
9
7 Technical Specifications
Table 4: Technical Specifications
1
of the VP-2xl 1:2 VGA Distributor
INPUTS: VIDEO: 1 VGA/XGA on an
HD15F connector
AUDIO: 1 audio stereo 1Vpp/10k on RCA
connectors
OUTPUTS: VIDEO: 2 VGA/XGA on HD15F
connectors
AUDIO: 2 audio stereo 1Vpp/150 on RCA
connectors (max.output 5 Vpp.)
BANDWIDTH: VIDEO: 340MHz AUDIO: 100 kHz
DIFF. GAIN:
0.04%
DIFF. PHASE:
0.07 Deg
VGA LEVEL CONTROL:
-0.7 to + 5.1dB
AUDIO CONTROL:
-55dB to + 6dB
AUDIO THD:
0.02%
AUDIO 2nd HARMONIC:
0.003%
VIDEO S/N RATIO:
VIDEO: 77dB
AUDIO 85dB
DIMENSIONS:
16.5cm x 12 cm x 4.5 cm (6.5” x 4.7” x 1.8”, W, D, H.)
POWER SOURCE:
12VDC, 100mA
WEIGHT:
0.7 kg. (1.5 lbs.) approx.
ACCESSORIES:
Power supply
OPTIONS:
VA-50P rack mountable power supply with six 12VDC outlets. RK-50RN rack
adapter
Table 5: Technical Specifications
1
of the VP-6xlN 1:6 UXGA Distributor
INPUTS: 1 XGA on an HD15F connector
OUTPUTS: 6 XGA on HD15F connectors
MAX. OUTPUT LEVEL: 1.7Vpp
BANDWIDTH: 500MHz
DIFF. GAIN: 0.09%
DIFF. PHASE: 0.01 Deg.
K-FACTOR: <0.05%
S/N RATIO: 72dB
CONTROLS: 0 to +10dB EQ.
COUPLING: DC
POWER SOURCE: 100-240 VAC, 50/60Hz, 18VA
DIMENSIONS: 19 inch (W), 7 inch (D) 1U (H) rack mountable
WEIGHT: 2.7 kg. (6 lbs.) approx.
ACCESSORIES: Power cord
1 Specifications are subject to change without notice
