Overview
2
3 Overview
Section 3.1 and section 3.2 describe the VP-2xl and VP-6xl
N
, respectively.
3.1 About the VP-2xl
The VP-2xl 1:2 VGA Distributor is a high performance, desktop size,
distribution amplifier for computer graphics signals, with resolutions ranging
up to at least UXGA, and unbalanced stereo audio signals. It takes one
computer graphics input, and an unbalanced stereo audio input, and outputs
two computer graphics and two unbalanced stereo audio signals. The VP-2xl:
Has a high bandwidth of 340MHz
Includes an AUDIO LEVEL control knob to adjust the audio signal level
Includes a VGA LEVEL control knob to adjust signal level,
compensating for cable loss over long distances
Is HDTV compatible
3.2 About the VP-6xl
N
The VP-6xl
N
1:6 UXGA Distributor is a high performance computer graphics
video amplifier for computer graphics video signals with resolutions ranging
up to at least UXGA, and is HDTV compatible. It takes one input, provides
correct buffering and isolation, and distributes the signal to six identical
outputs. The VP-6xl
N
features:
A video bandwidth of 500MHz that ensures transparent operation at all
graphics resolutions
ID Bit control underside switches
A front panel trimmer for UXGA equalization
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise-
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your Kramer unit away from moisture, excessive sunlight and dust
4 Your Distributors
This section includes a description of the:
VP-2xl 1:2 VGA Distributor (see section 4.1)
VP-6xl
N
1:6 UXGA Distributor (see section 4.2)
