VS-211HA - Operating the VS-211HA

5 Operating the VS-211HA

The VS-211HA works in three modes:

 Manual mode (see Section 5.1)

 Automatic mode (see Section 5.2)

 Override mode (see Section 5.3)

5.1 Using the Manual Mode

In manual mode the VS-211HA only switches when the remote contact closure

switches are momentarily pressed. If you switch to an inactive input source, the

output is blank.

Note: A source is considered active only when there is an active clock signal coming from the

source.

To set manual mode:

 Slide the AUTO/MANUAL DIP 1 down to MANUAL (see Figure 1)

 Select the required port manually by pressing the switches connected to the

terminal block

5.2 Using the Automatic Mode

Automatic mode uses automatic signal detection to determine the device’s

behavior during switching. Automatic mode has two further modes: Priority mode

and Last connected mode.

In Automatic/Priority mode, Input 1 has the higher priority

 If two sources are connected and active, Input 1 is sent to the output

 If Input 1 becomes inactive, Input 2 is sent to the output

 If Input 1 returns to activity, Input 1 is sent to the output

For example, a sports bar has an AV system that displays live sports action on Input 1

while commercials loop on Input 2. If the game is interrupted, commercials automatically

display until the live action returns.
