Hex Table (Protocol 2000)
17
17
11 Hex Table (Protocol 2000)
The following sections describe the Hex values (which the protocol in Section
13.4 describes in more detail) for the VP-27 Presentation Switcher. RS-232
communication is at 9600 baud, no parity, 8 data bits and 1 stop bit.
11.1 The Switching Control Hex Table
Table 6 lists the Hex values for the Video and Audio In-group Selector:
Table 6: VP-27 Hex Table Video and Audio In-group Selector
Inputs
CV OUT Y/C OUT PC OUT Master Audio
Group #
CV
In 1 01 81 81 81
In 2 01 82 81 81
In 3 01 83 81 81
In 4 01 84 81 81
Y/C
In 1
01 81 82 81
In 2 01 82 82 81
In 3 01 83 82 81
In 4 01 84 82 81
PC
In 1
01 81 83 81
In 2 01 82 83 81
In 3 01 83 83 81
In 4 01 84 83 81
Master Audio
Group
input
CV
02 81 80 81
Y/C 02 82 80 81
PC 02 83 80 81
Mic 02 84 80 81
11.2 Audio Gain Control Hex Tables
The following tables describe the audio gain controls.
Table 7: Set the Audio Gain Control for the Groups
VGA 1 Y/C PC
Notes
16 81 80 81 16 82 80 81 16 83 80 81 Mute
…
…
…
16 81 F1 81 16 82 F1 81 16 83 F1 81 0dB (1:1)
…
…
…
16 81 FF 81 16 82 FF 81 16 83 FF 81 Maximum
Table 8: Set the Audio Output Gain Control for the Microphone
Audio Gain Control for Microphone
16 84 80 81 Mute
…
16 84 EB 81 0dB (1:1)
…
16 84 FF 81 Maximum
