Technical Specifications
15
15
9 Technical Specifications
Table 4 includes the technical specifications:
Table 4: Technical Specifications
1
INPUTS:
of the VP-27 Presentation Switcher
4 composite video on RCA connectors
4 s-Video on 4-pin connectors
4 PC on 15-pin HD connectors
4 unbalanced stereo audio on RCA connectors, L+R (for CV)
4 unbalanced stereo audio on RCA connectors, L+R (for Y/C)
4 unbalanced stereo audio on 3.5mm jack connectors (for PC)
Mic: 3mV / 10kΩ condenser / dynamic on a 6.3mm Phone Jack connector
OUTPUTS: 1 composite video on an RCA connector
1 s-Video on a 4-pin connector
1 PC on a 15-pin HD connector
1 master audio on an RCA connector, L+R
1 unbalanced stereo audio on an RCA connector, L+R (for CV)
1 unbalanced stereo audio on an RCA connector, L+R (for Y/C)
1 unbalanced stereo audio on a 3.5mm jack connector (for PC)
MAX. OUTPUT LEVEL: VIDEO: CV and Y/C: 1.8Vpp
PC: 2Vpp
AUDIO: CV and Y/C: 1.8Vpp; mic:
6.2Vpp, PC: 6.2Vpp; master: 6Vpp
BANDWIDTH (-3dB): CV: 683MHz; Y/C: 725MHz; PC:
415MHZ
AUDIO:CV and Y/C: >40kHz; mic:
22.6kHz; PC: >40kHz; master:
22.5kHz
DIFF. GAIN: CV and Y/C: 0.03%; XGA: 0.05%
DIFF. PHASE: CV and PC: 0.03 Deg.; Y/C: 0.02Deg.
K-FACTOR: <0.05%
S/N RATIO: VIDEO (@5MHz): CV: 75.1dB;
Y/C: 78.7dB; PC: 74.4dB
AUDIO (@1MHz): CV and Y/C:
78.5dB; PC: 78dB; mic: 52dB
CROSSTALK (all hostile): VIDEO(@5MHz): CV: -50.5dB;
Y/C: -33dB; PC: -51.5dB
AUDIO: -68.9dB @1MHz, -43.3dB
@20kHz (YC)
CONTROLS: MUTE, TALK OVER, MIX, LOCK, switching front panel buttons,
RS-232, rear panel dipswitches, volume for line: -62dB to +14.1dB;
mic volume: -17dB to +69.5dB
COUPLING: VIDEO: DC AUDIO: AC
AUDIO THD + NOISE (@1kHz): YC: 0.092%; PC: 0.024%
AUDIO 2nd HARMONIC
(@1kHz):
YC and PC: 0.03%
POWER SOURCE: 100-240V AC, 6VA max.
DIMENSIONS: 19-inch (W), 7-inch(D) 1U (H) rack mountable
WEIGHT: 2.7kg (6 bs) approx
ACCESSORIES: Power cord, Windows®-based control software
1 Specifications are subject to change without notice
