KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VP-27 Presentation Switcher
6
Table 2: Rear Panel VP-27 Presentation Switcher Features
#
Feature
Function
18 Video
Connectors
Y/C IN 4-pin Connect to the s-Video sources
2
19 CV IN RCA Connect to the composite video sources
2
20 Y/C OUT 4-pin Connect to the s-Video acceptor
21 CV OUT RCA Connect to the composite video acceptor
22 PC IN 15-pin HD Connectors Connect to the VGA/UXGA video sources
2
23 PC OUT 15-pin HD Connector Connect to the VGA/UXGA video acceptor
24 DIP-switches DIP-switches for setup of the unit (DIP 1 and 4 are not used; DIP
2 PROG
1
6.2, DIP 3 MIC DC; see Section )
25 RS-232 (Tx, Rx, G) Terminal
Block Connector
Connects to the PC or the Remote Controller
26 PC AUDIO IN 3.5mm Mini Plugs Connect to the s-Video unbalanced audio sources
2
27 PC AUDIO OUT 3.5mm Mini
Plug
Connect to the PC unbalanced stereo audio acceptor (for the PC
video)
28 MIC 6.3mm Phone Jack Connector
Connect to the microphone
29 CV AUDIO IN RCA Connectors Connect to the unbalanced audio sources
2
30
of the composite
video
CV AUDIO OUT RCA
Connectors (L and R)
Connect to the composite video unbalanced audio acceptor (for
the composite video)
31 Y/C AUDIO IN RCA Connectors Connect to the s-Video unbalanced audio sources
2
32 Y/C AUDIO RCA Connectors (L
and R)
Connects to the s-Video unbalanced audio acceptor (for the
s-Video)
33 MASTER OUT RCA Connectors
(L and R)
Connect the master unbalanced audio channel acceptor
34 Power Connector with Fuse AC connector enabling power supply to the unit
35 POWER Switch Illuminated switch for turning the unit ON or OFF
1 Always set to OFF (for factory use)
2 From 1 to 4
