VP-28 - Connecting the VP-28 11
11
5.2 Connecting to the VP-28 via Ethernet
You can connect the VP-28 via Ethernet via either of the following methods:
• A crossover cable (see Section
5.2.1) for direct connection to the PC
• A straight through cable (see Section
5.2.2) for connection via a network hub
or network router
After connecting the Ethernet port, you have to install and configure your Ethernet
Port. For detailed instructions, see the Ethernet Configuration Guide (Lantronix) in
the technical support section on our Web site
http://www.kramerelectronics.com.
5.2.1 Connecting the Ethernet Port directly to a PC
You can connect the Ethernet port on the VP-28 to the Ethernet port on your PC
via a crossover cable with RJ-45 connectors. This type of connection is
recommended for identification of the factory default IP Address of the VP-28
during the initial configuration.
To configure your PC after connecting the Ethernet port:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button.
