Instructions for the user
34
3. DESCRIPTION OF CONTROLS
3.1 Front control panel
All the cooker controls and commands are on the front panel.
The user has only to press the central key for 1 - 2 seconds to enable
use of the oven on first use or after a power blackout.
DESCRIPTION OF SYMBOLS
OVEN THERMOSTAT
CENTRAL
COOKING ZONE
OVEN FUNCTIONS
REAR RIGHT-HAND
COOKING ZONE
FRONT LEFT-HAND
COOKING ZONE
FRONT RIGHT-HAND
COOKING ZONE
REAR LEFT-HAND
COOKING ZONE
THERMOSTAT KNOB
The cooking temperature is selected by turning the knob
clockwise to the required setting, between 50° and 250°C.
The light comes on to indicate that the oven is heating up.
When it goes out it means that the required temperature
has been reached. Regular flashing means that oven
temperature is being constantly maintained at the
programmed level.
COOKING HOB INDICATOR LIGHT (A)
Indicator light A switches on to indicate that one or more of the cooking
zones are heating. When all knobs are set to 0, the light goes off.
