RC-53DLC - Overview

3 Overview

The RC-53DLC is an auxiliary remote control panel for Master Room Controllers

(such as the Kramer SummitView System or the SL-1 Master Room Controller)

for controlling AV equipment in a room.

The RC-53DLC features:

 Six front panel, backlit buttons designed in two groups; one group of two

buttons, and another group of four buttons

256 colors are available for backlit buttons (to be configured by the system integrator).

The colors of each button can be programmed with flexible RGB values.

 A digital volume control adjustment knob

 A 2 gang wall plate for the USA and for Europe

 K-NET operation - does not require a separate power supply

 An RS-232 serial port

 Two K-NET ports and a USB port for firmware upgrade

 Two programmable LCD displays, one for each button group

3.1 Defining the RC-53DLC K-NET™ Auxiliary Control Panel

This section defines the RC-53DLC US (see Section 3.1.1) and European (see

Section 3.1.2) versions.
