4 WP-110 XGA Line Transmitter

The Kramer Wall Plate WP-110 is an XGA line transmitter that receives an XGA

signal and transmits it over a CAT 5 cable to the PT-120xl or TP-120 receiver. The

WP-110 is available in three versions: one for USA, one for Belgium and Germany,

and one for UK and most of Europe (excluding Belgium and Germany). In

particular, the WP-110 features:

 Resolution of up to XGA

 Transmission range over 100m (320ft)

 Use of the simplest UTP CAT 5 cables, however, it benefits from better

quality cables

 The power connect feature and is 12V DC fed

4.1 Your WP-110 XGA Line Transmitter

The WP-110 is available in three versions: US, Belgium and Germany, and UK

and most of Europe (excluding Belgium and Germany), as defined in Figure 3:
