![Kramer TP-104HD [15/33] Your tp122 xga audio line receiver underside](/views2/1152823/page15/bgf.png)
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your TP-121/TP-122
12
6.2.2 Your TP-122 XGA/Audio Line Receiver (Underside)
Figure 8 and Table 7 define the underside
1
of the TP-122 XGA/Audio Line
Receiver:
Figure 8: TP-122 XGA/Audio Line Receiver (Underside
1
)
Table 7: TP-122 XGA/Audio Line Receiver (Underside) Features
#
Feature
Function
1 VS Switch Slide the switch up
2
to set the V SYNC to positive polarity;
slide the switch down to set the V SYNC to negative polarity
2 HS Switch Slide the switch up
2
to set the H SYNC to positive polarity;
slide the switch down to set the H SYNC to negative polarity
1 The underside is identical on the TP-122 and TP-124
2 By default, both switches are set down (for a negative V SYNC and H SYNC polarity)
