TP-121xl/TP-122xl - Technical Specifications
8 Technical Specifications
TP-121xl
TP-122xl
INPUTS:
1 UXGA on a 15-pin HD
connector (F)
1 Unbalanced stereo audio on a
3.5mm mini jack
1 TP on an RJ-45 connector
OUTPUTS:
1 TP on an RJ-45 connector
1 UXGA on a 15-pin HD connector (F)
1 Digital audio on an RCA connector
1 Unbalanced stereo audio on a
3.5mm mini jack
VIDEO RESOLUTION:
Up to WUXGA, 1080p
MAX. OUTPUT LEVEL:
Video: 1.1V
Audio: 2.2V
AUDIO:
BANDWIDTH:
Audio: 20Hz-20kHz @–3dB
S/N RATIO:
Audio: 84dB unweighted
COUPLING:
AC
TND+N:
Audio: 0.02% unweighted
TOTAL GAIN:
Analog/analog: 0dB
Analog/SPDIF: –12dBFS
POWER CONSUMPTION:
12V DC 190mA (380mA when
powering both devices)
12V DC 220mA (380mA when
powering both devices)
TRANSMISSION DISTANCE:
Up to 250m (820ft)
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
–40° to +70°C (–40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.18cm x 2.48cm (4.76" x 2.83" x 0.98"), W, D, H
WEIGHT:
0.2kg (0.44lbs.) approx. each
INCLUDED ACCESSORIES:
Power supply
OPTIONS:
RK-3T 19” rack adapter
