KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
12
6 Technical Specifications
The TP-100AXR, TP-200AXR technical specifications
1
are shown in
Table 4:
Table 4: TP-100AXR, TP-200AXR Technical Specifications
TP-100AXR TP-200AXR
INPUTS: 1 VGA on a 15-pin HD connector
1 analog audio on a 3.5mm mini jack
1 RJ-45 LINE IN connector
OUTPUTS: 2 RJ-45 OUT connectors
1 VGA loop on a 15-pin HD connector
1 analog audio loop out on a 3.5mm
mini jack
1 RJ-45 line loop out
2 VGA on 15-pin HD connectors
2 S/PDIF on RCA connectors
2 audio analog 3.5mm mini jacks
MAX. OUTPUT LEVEL: – Video: 1.8V, audio: 2.9V
CONTROLS: – Level: –7dB to +4dB,
EQ.: 0dB to +16dB (60m) @ 50MHz
RESOLUTION: Up to WUXGA
BANDWIDTH (-3dB)
2
20kHz :
S/N RATIO: Video: 60dB; Audio: <89dB
TOTAL GAIN: Analog/analog: 0dB
Analog/SPDIF: –12dBFS
COUPLING: AC
THD+N: Audio: 0.25%
POWER SOURCE: 12V DC, 860mA 12V DC, 860mA
DIMENSIONS: 21.5cm x 16.3cm x 4.4cm (8.6" x 7" x 1.8") W, D, H
WEIGHT: 1.1kg (2.4lbs)
ACCESSORIES: Power supply
OPTIONS: RK-1 19” rack mount adapter
1 Specifications are subject to change without notice
2 For the Transmitter/Receiver pair
