Smeg PDXF116RS [17/18] Instructions for the installer
![Smeg PDXF116RS [17/18] Instructions for the installer](/views2/1015330/page17/bg11.png)
37
Instructions for the Installer
10.2 Burner and Nozzle Data Tables
Burner
RATED
HEAT
CAPACITY
(
KW)
LPG – G30/G31 28/37 mbar
Nozzle
diameter
1/100 mm
By-pass
mm
1/100
Reduced
heat
capacity
(W)
Net
g/h G30
Net
g/h G31
Auxiliary (!) 1.05 50 30 * 28 ** 350 76 75
Semi-rapid (2) 1.75 65 33 * 32 ** 450 127 125
Rapid (3) 2.3 75 45 * 42 ** 800 167 164
Fish pan (4) 1.9 68 45 * 42 ** 900 138 136
*/**: diameters marked * and ** must be fitted respectively on valves marked * and
**shown in point "11.1 Adjusting the minimum setting for natural gas".
Burner
RATED
HEAT
CAPACITY
(
KW)
NATURAL GAS – G20 20 mbar
Nozzle diameter
1/100 mm
Reduced heat capacity
(W)
Auxiliary (!) 1.05 72 350
Semi-rapid (2) 1.75 97 450
Rapid (3) 2.5 108 800
Fish pan (4) 1.9 94 900
To identify the burners on your hob, refer to the drawings in point "4.
GETTING TO KNOW YOUR APPLIANCE".
