Overview

3 Overview

The Kramer VA-1DVIN is a unique DVI EDID emulator, with a DVI-D

input and DVI-D output on DVI-I connectors

. When connecting the

VA-1DVIN to a display device and pressing the CAPTURE EDID button,

the VA-1DVIN reads and stores the EDID (Extended Display Identification

Data) from the display device

. For example, when the DVI signal is

extended more than 100 meters over fiber optic cable, the VA-1DVIN can

emulate the EDID information

. The display can be disconnected and later

reconnected, without rebooting the operating system.

Note: The VA-1DVIN does not pass HDCP signals.

In addition, the VA-1DVIN:

• Features a maximum data rate of 3.3Gbps

• Is housed in a Pico TOOLS enclosure

• Is fed from a 5V DC power supply

To achieve the best performance:

• Connect only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching, and

elevated noise- levels (often associated with low quality cables)

• Avoid interference from neighboring electrical appliances and position

your Kramer VA-1DVIN away from moisture, excessive sunlight and dust

1 Available for digital signals (DVI-D). Analog signals (DVI-I) are passed unchanged between the input and the output

2 The computer needs to have the EDID information available when it boots up, otherwise the DVI output will be disabled

3 The DDC (Digital Display Channel) cable has no effect for distances over 100 meters

4 Four units can be rack mounted side-by-side in a 1U rack space with the optional RK-4PT rack adapter
