Connecting the VA-1DVIN Virtual EDID

Figure 2: VA-1DVIN – Acquiring the EDID from the Display Device

5.2 Reconnecting the Projector

To reconnect the projector at a distance from the PC, as illustrated in the

example in Figure 3

, do the following

1. Connect a DVI source (for example, a DVI computer graphics source) to the

INPUT DVI connector on the VA-1DVIN.

Turn on the DVI source only after connecting the VA-1DVIN, so it can acquire

the EDID properly

2. If required

, connect the 5V DC power adapter to the power socket and

connect the adapter to the mains electricity.

3. When installation is complete

, connect the OUTPUT DVI connector of the

VA-1DVIN to the projector, using the required cable length.

1 Switch OFF the power on each device before connecting it to your VA-1DVIN

2 Usually, the PC can supply power to the unit

3 The EDID is transmitted to the PC via the VA-1DVIN, so the PC gets the EDID information even if the projector is

temporarily disconnected. When installing the display again at a distance, there is no need to reboot the PC
