Kramer VP-796 Руководства по эксплуатации онлайн [10/38] 140340

of December 2015 10

VP SYSTEM DESCRIPTION

3.1.

Product Overview

The unit designed to accept the following input signals:

Model

VP-796

VP-797

VP-798

2x 3G-SDI/HD-SDI/SDI

(Serial Digital Interface) via BNC





Display Port

via DP connector



2x HDMI (4k)

via HDMI connector



HDBaseT

Via RJ45 connector



DVI via DVI-U

(supporting a digital and a YPbPr input)



VGA analogue via 15HDD



Composite Video

via BNC



HDMI (1080p deep color)

via HDMI connector



3.2.

Product Specification

This section provides technical details for all possible inputs.

3.2.1.

Power Supply Requirement

100V-264VAC 50/60Hz connected via a standard IEC connector located on the rear panel.

3.2.2.

Video Inputs

Composite via BNC connector

Signal formats Composite (CVBS)

Standards NTSC, PAL, SECAM

Composite (CVBS) input level 1V p-p nominal incl. sync

Input Impedance 75 Ohms

3.2.3.

Component Video Inputs

Via DVI-U connector and appropriate adapter cable

YPbPr (YUV), YPbPrS and RGsB component video, menu selectable.

Signal formats 484i (480i) and 576i (SD), 480p, 576p (ED), 720p, 1080i at 50, 59.94 and 60Hz and

1080p at 23.98, 24, 25, 29.97 and 30Hz.

Please note this input does not support Computer SVGA signals which should be connected via the

Computer SVGA input, The SVGA input supports the separate H & V syncs.
