of December 2015 11

3.2.4.

Computer (SVGA) Inputs VESA formats

Signal formats: DOS, VGA – WUXGA up to 165MHz pixel clock

RGB video level 0.7V - 1.0V

RGB input impedance 75 Ohms

Sync format Separate H & V sync at TTL/5V levels.

3.2.5.

HDMI & DVI Inputs

HDMI with or without HDCP, 36-bit video compatible.

DVI-D input with or without HDCP

Signal formats - video

SD: 625i (576i) and 525i (480i) in double-rate formats; ED: 480p, 576p; HD: 1280x720p, 1920x1080i,

1920x1080psf; 1920x1080p 23.97, 24, 25, 29.94, 30, 50, 59.94 & 60Hz; 2048x1080p 23.97, 24, 25,

29.94, 30, 50, 59.94 & 60Hz.

The 4k capable HDMI 1 and HDMI 2 inputs also support: 3840x2160p & 4096x2160p 23.97, 24, 25,

29.94, 30, 50, 59.94 & 60Hz (50, 59.94 & 60Hz supported in YUV 4:2:0 colour space format),

Signal formats – computer

Common VESA graphics formats from VGA to 4k up to 297 MHz (HDMI 1 and HDMI 2) and 225 MHz

(HDMI 3) pixel clock

Note: As of now HDMI1/2 and HDBT inputs support RGB and YUV 4:2:0 colour space formats. Signals

with YUV 4:4:4 and YUV 4:2:2 colour space formats need to be connected to the HDMI3 or DVI input.

Note: Graphics formats with odd numbered horizontal active pixels, e.g. 1365x768 are currently not

supported.

3.2.6.

DP Input

Display Port without HDCP, 36-bit video compatible.

Signal formats as HDMI 1 and HDMI 2.

3.2.7.

HDBT Input

Uncompressed HD video over RJ45 connector and max.100m CAT5e cable (or better)

CAT5e/CAT6 for 100m and signals with less than 225MHz Pixel Clock

CAT6a/CAT7 for 100m and signals up to 297MHz Pixel Clock

Signal formats as HDMI 1 and HDMI 2.
