3.2.8.

Audio Output

Audio is embedded in HDMI video streams and brought into the unit through the respective input

channels. The audio is passed through the system and re-embedded into the HDMI output signals.

Also, the unit features a S/PDIF coaxial digital audio output connector for monitoring audio of the HDMI

channel.

When HDMI is selected as the input channel the HDMI EDID is read by a video source such as a Blue

Ray Player. The unit allows the source to provide the formats shown under output formats for HDMI in

the below table.

All formats are re-embedded into the HDMI output data stream, those which are not allowed on SPDIF

output are muted on the individual channels.

Output Channel

Output Format

HDMI

PCM up to 8ch, up to 24Bit, up to 192kHz sampling rate

(incl. 32kHz,44.1kHz,48kHz,96kHz,192kHz)

Dolby Digital (AC3) up to 5.1 channels, up to 640kBit/sec bit stream rate

MPEG2 up to 8ch, up to 112kBit/sec bit stream rate

DTS up to 6.1 channels, up to 1536kBit/sec bit stream rate

SPDIF

PCM up to 2ch, up to 24Bit, up to 96kHz sampling rate

(incl. 32kHz,44.1kHz,48kHz,96kHz)

Dolby Digital (AC3) up to 5.1 channels

DTS up to 6.1 channels
