3.2.9.

Display Output

Three output channels are provided which are useable simultaneously. That is an HDMI, a DVI-I output

connector for DVI/HDMI connectivity and an RJ45 connector for HDBaseT connectivity.

When the input signal has HDCP encryption, the DVI-D, HDMI and HDBaseT output connectors will

carry a similarly HDCP encrypted signal.

When an HDCP encrypted signal is input, but the display device does not support HDCP, the

output image will turn black and a message indicating HDCP Signal will come up to the LCD

menu screen to indicate this.

There is a DVI-D and HDMI output. Both conform to normal VESA standards for connectors and pin

outs for these signal types.

The DVI-D connector will support HDMI with 36-bit video and audio formats when connected to a

suitable HDMI receiver. The colour depth of the HDMI signal is determined by the set-up of the unit and

the capabilities of the monitor.

4096x2160 currently is supported at 23.97/24Hz/29.97/30/50. 4096x2160 at 59.94/60 is not supported.

Note: The processor’s HDCP compliance can be turned off. This is of importance particularly

when using a MAC computer as the source. A MAC will encrypt its output signal if a compliant

device is seen attached to its output regardless of copy protection requirements to the content.

By turning off the unit processor’s compliance the MAC will see a non-compliant device and

therefore will not encrypt its output. When HDCP compliance is turned off encrypted sources

will not be displayed.

Note: The DVI/HDMI1 output of HDBaseT enabled products works fine with most displays at 4k.

However, this cannot be guaranteed. There may be occasional short video drop outs which

immediately recover. The frequentness depends on the display input electrical circuitry, the

input format measurement of the display and the quality of the cable being used.
