WD and WX Series Passive Wall Plate Connection Modules
Congratulations on purchasing your Kramer WD and/or WX series
passive wall plate connection module, which is ideal for the
following applications:
Board, conference and training rooms
Presentation systems
Home theater
WD Series DB-9 Passive Wall Plate Connection Modules (WD-2F, WD-MF,
WD-2M, WD-FM), used, for example, for RS-232 Serial connection:
The WD-2F is a Female DB-9 to Female
DB-9 connection module.
The WD-MF is a Male DB-9 to Female
DB-9 connection module.
The WD-2M is a Male DB-9 to Male DB-9
connection module.
The WD-FM is a Female DB-9 to Male
DB-9 connection module.
WD Series DB-9 front panel showing
female connector:
WD Series DB-9 rotated view:
PIN
1
PIN
6
PIN
9
PIN
5
WX Series HD-15 Passive Wall Plate Connection Modules (WX-2F,
WX-MF, WX-2M, WX-FM, and WX-F5B*), used, for example, for the
connection of computer graphics video signals (VGA, XGA, and so on).
The WX-2F is a Female VGA to Female
VGA connection module.
The WX-MF is a Male VGA to Female
VGA connection module.
The
WX-2M
is a Male VGA to Male VGA
connection module.
The
WX-FM
is a Female VGA to Male
VGA connection module.
WX Series HD-15 front panel showing
female connector:
WX Series HD-15 rotated view:
PIN
1
PIN
5
PIN
11
PIN
15
PIN
6
PIN
10
* See next page
