Kramer WX-2F [2/2] Wd and wx series passive wall plate connection modules

The WX-F5B module is an HD-15F connector to RGBHV on 5 color-coded male BNC

connectors. The WX-F5B is ideal for connecting a computer graphics video source to a

projector or other display.

Vertical Sync (Black)

Green (G)

Blue (B)

Horizontal Sync (Yellow)

Red (R)

WD and WX Series Passive

Wall Plate Connection Modules



WD Series (DB 9):



WD-2F, WD-MF, WD-2M, WD-FM

WX Series (HD 15):

WX-2F, WX-MF, WX-2M, WX-FM, WX-F5B



For the latest information on our products and a list of Kramer distributors, visit our

Web site: www.kramerelectronics.com



Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: info@kramerel.com

P/N: 2900-000089 REV 2
