Kramer RK-1 [11/13] To the rk 1 to cover any empty spaces as the example in figure 5 illustrates

Technical Specifications

5.2 Connecting a Blank Panel to the RK-1

You can connect a blank panel

to the RK-1 to cover any empty spaces, as the

example in

Figure 5 illustrates:

Figure 5: RK-1 Rack Adapter – Connecting a Blank Panel

6 Technical Specifications

Table 5 includes the technical specifications:

Table 5: Technical Specifications

DIMENSIONS:

of the RK-1

19-inch (W), 7-inch (D) 1U (H)

WEIGHT: 1.2kg. (2.65lbs.) approx.

ACCESSORIES: 20 M3x5 screws, 1 half-19" 1U blank panel

OPTIONS:

Blank panels

1 Specified in Section 6

2 Specifications are subject to change without notice

3 P/N: 60-900013

4 See

Table 3
