KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
2
• 6.5"-1U units—for example, two VM-50V units with a short blank panel
in between them, or one VM-50V unit with a short blank panel and a
long blank panel (see
Table 2)
3.1 RK-1 Installation combinations
Table 1 shows examples of how you can use the RK-1 to mount different
combinations of products:
Table 1: Using the RK-1
Mounting Kramer Products
1
For example:
on the RK-1
• Two PIP-4 units
• Two VP-5xl units
• One PIP-4 unit
• Two FC-31xl units
• One PIP-4 unit
• One FC-31xl unit
• One PS-1DVI unit
• One PT-1PS unit
• One PIP-4 unit
• Two PS-1DVI units
• Two PT-1PS units
• Two FC-31xl units
• Two 102xl units
• Two FC-31xl units
• One 102xl unit
• Two PS-1DVI units
• Two 102xl units
• Two PS-1DVI units
• Two PT-1PS units
• One FC-31xl unit
• Three PS-1DVI units
• Three PT-1PS units
• Four PS-1DVI units
• Four PT-1PS units
1 Each product is measured in inches
