Kramer RK-1 [7/13] Your kramer rk 1 rack adapter

Your Kramer RK-1 Rack Adapter

4 Your Kramer RK-1 Rack Adapter

The example in Figure 1 illustrates the mounting of:

• One 1/2-19" unit (for example, the Kramer PIP-4)

• One 1/4-19” 1U unit (for example, the Kramer MultiTOOLS® FC-31xl)

• Two 1/8-19” 1U units (for example, two Kramer MultiTOOLS® PS-1DVI)

Figure 1: RK-1 Rack Adapter

You can order additional blank panels to cover a 1/4-19” 1U opening

and/or a

1/8-19” 1U opening

on the RK-1

1 Part number 60-900014

2 Part number 60-900015
