KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
The examples in Table 4 indicate how to install different products together
with blanks:
Table 4: Using the RK-1 with Blank Panels
Mounting Kramer Products with Blank Panels on the RK-1
For example:
• One PIP-4 unit
• One 1/2 19” blank panel
• One 1/2 19” blank panel
• One 1/4 19” blank panel
• One FC-31xl unit
• One PIP-4 unit
• One FC-31xl unit
• One 1/8 19” blank panel
• One PT-1PS unit
• One VM-50V unit
• One SHORT blank panel
• One LONG blank panel
• One VM-50V unit
• One SHORT blank panel
• One VM-50AN unit
3.2 Recommendations for Best Performance
We recommend that you:
• Have a Philips screwdriver and an Allen screwdriver available
• Disconnect the mains voltage and all cables connected to each machine that
is being mounted in the rack adapter before proceeding with the installation
• Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
• Avoid interference from neighboring electrical appliances and position your
rack adapter on the rack away from moisture, excessive sunlight and dust
