SPK-C611 - Overview 3
3
3 Overview
The SPK-C611 speakers include a pair of high performance Open-back Ceiling
speakers that can be mounted on the ceiling. The optional Kramer Suspended
Ceiling Speaker Mounting Kit (SKIC) can safely secure the speakers to the ceiling
as well.
Figure 1 shows an example of how the Open-back Ceiling speakers can be
installed in a boardroom setup:
Figure 1: Open-back Ceiling Speakers in a Boardroom Setup
