Kramer VS-406 [11/13] Technical specifications

Technical Specifications

7 Technical Specifications

The VS-406 technical specifications are shown in Table 2:

Table 2: VS-406 Technical Specifications

INPUTS:

1 unbalanced stereo audio on RCA connectors

OUTPUTS: 6 powered speakers on springed terminal blocks;

10 line level unbalanced audio stereo on RCA connectors

INPUT SENSITIVITY: 0.5Vpp @38dB total gain

MAXIMUM OUTPUT LEVEL: 40Vpp @10% THD + N, 33W/channel, 8Ω full load

MAX. VOLTAGE GAIN: +38dB

BANDWIDTH (-3dB): 20kHz

S/N RATIO: 74dB @10% THD + N

CONTROLS: Volume level range: -51dB to 38dB (internal gain switches are

set to 38dB)

COUPLING: Input – AC, output – DC

AUDIO THD + NOISE: 0.2% @ 2W into 8Ω

AUDIO 2nd HARMONIC: 0.16% @ 2W into 8Ω

AMPLIFIER TYPE: Class D

POWER SOURCE: 24V DC, 3.6A

DIMENSIONS: 19” x 4.0” x 1U

WEIGHT: 1kg (2.2lbs)

ACCESSORIES: Power supply, rack “ears”

1 Specifications are subject to change without notice
