Connecting and Operating the VS-406

6 Connecting and Operating the VS-406

To connect the VS-406, as shown in Figure 2, do the following

1. Connect an unbalanced stereo audio source (for example, a stereo audio

player) to the LINE INPUT L and R RCA connectors.

2. Connect the LINE OUTPUT RCA connectors to up to 10 unbalanced

stereo audio acceptors (for example, stereo audio recorders).

3. Connect the OUT (SPKR) connectors to up to 6 speaker pairs (use only

passive, unpowered speakers).

4. Connect the 24V DC power supply.

To operate the VS-406:

1. Press the appropriate button on the LINE OUT SELECTOR (from 1 to

10) or the LOUDSPEAKER OUT SELECTOR (from 11 to 16).

The line input switches to the selected line output or speaker.

2. Adjust the speaker volume by turning the LOUDSPEAKER VOLUME

knob.

Note: The power supply is only needed when operating loudspeakers.

No power is needed for line switching.

1 Switch OFF the power on each device before connecting it to your VS-406. After connecting your VS-406, connect its

power and then switch on the power on each device
