17
GB
3 Operating
Next this program is shown with reverse directions of rotation and middle
vibration intensity level. Closing the demo program massage in the seat is
activated once more showing highest vibration intensity level. The LEDs schow
the current massage regions and functions. The device will stop once all func-
tions worked.
Neck button
Switch on the device by pressing On/Off button
.
Neck button
is for the neck/shoulder reversible kneading massage. Press this
button once, left massage head
is kneading counterclockwise; right massage
head
is kneading clockwise. Press it a second time, left massage head
is
kneading clockwise; right massage head
is kneading counterclockwise. Press
button
a third time, neck massage stops.
Back buttons
Switch on the device by pressing On/Off button
.
Select the region you wish to massage with the back massage button
(
/
/
) .
Full button
(full back)
The Shiatsu massage heads
move from the “Park” position at the base of
the backrest, up to the shoulder area, massaging the back in a circular motion
whilst doing so. Once the uppermost position has been reached, the direction
of rotation of the massaging heads is reversed. The heads then travel down to
the base of the backrest. Once the heads reach this point, the direction of rota-
tion is reversed again and then travel up the back again.
Upper button
(upper back)
The Shiatsu massage heads
travel up and down the upper half of the back
in a circular motion. The reversal of the direction of rotation takes place when
the respective end positions are reached.
Lower button
(lower back)
The Shiatsu massage heads
travel up and down the lower half of the back
in a circular motion. The reversal of the direction of rotation takes place when
the respective end positions are reached.
Heat button
The heat function can be activated at any time with the shiatsu massage, dur-
ing which the vibration massage can also be activated. Press the heat button
to activate the function; the LED on the control unit and the massage heads
light up red. The heat is radiated through the massage heads
. Press the
button
again to de-activate the heat function; the LED and the red light of
the massage heads go out.
88930_MCN_WEST_Final.qxd:Massagesitz 04.01.2011 16:53 Uhr Seite 17
