Type 4-stroke, vertical cylinder, air-cooled diesel engine

No. of Cylinders 1

Bore x Stroke (mm) 86 x 75

Displacement (litres) 0.435

Continuous Rated Output

r/min

-1

3600 3200 2500

HP SAE 8.3 7.8 6.7

kW 6.2 5.8 5.0

PS 8.4 7.9 6.8

Max Rated Output

r/min

-1

3600 3200 2500

HP SAE 9.1 8.7 7.4

kW 6.8 6.5 5.5

PS 9.3 8.8 7.5

High Idling r/min

-1

3800 3450 2700

Dry Engine Weight

with Electric Start (lbs/kg) 118 / 53.5

Dry Engine Weight

without Electric Start (lbs/kg) 107 / 48.5

Cooling System Forced Air by Flywheel Fan

Lubrication System Forced lubrication with Trochoid Pump

Starting System Electric Start / Recoil Start

Dimensions (inches/mm)

Length x Width x Height 16.2 / 412 x 18.5 / 471 x 19.4 / 494

Engine Oil Pan Capacity

Dipstick Upper Limit 1.7 qt / 1.6 litres

Dipstick Lower Limit 1.06 qt / 1.0 litres

Fuel Tank Capacity (recommended) 5.0 qt / 4.7 litres

YANMAR L100V

6.8kW (9.1hp) @

3600r/min

-1
