EN_DS3YM30AE_0415
www.yanmar.eu
Configuration 4-stroke, vertical, water-cooled diesel engine
Maximum output at crankshaft * 21.3 kW@3200 rpm [29.1 mhp@3200 rpm]
Displacement 1.266 ltr [77 cu in]
Bore x stroke 80 mm x 84 mm [3.1 in x 3.3 in]
Cylinders 3
Combustion system Indirect injection
Aspiration Natural aspiration
Starting system Electric starting 12V - 1.4 kW
Alternator 12V - 125A
Cooling system Fresh water cooling with heat exchanger
Lubrication system Enclosed, forced lubricating system
Direction of rotation [crankshaft] Counterclockwise viewed from flywheel side
Dry weight without gear 127 kg [280 lbs]
Environmental EU: RCD BSO II EMC
US: EPA Tier3
Engine mounting Rubber type flexible mounting
NOTE:
Fuel condition: Density at 15°C = 0.84 g/cm³; 1 kW = 1.3596 mhp = 1.3410 HP
* Fuel temperature 40°C at the inlet of the fuel injection pump [ISO 8665:2006]
Technical data is according to ISO 8665: 2006
DIMENSIONS
3YM30AE with KM2P-1 marine gear
Rear view Right side view
3YM30AE Series
MARINE DIESEL ENGINES
