EN_DS4JH110_1214
www.yanmar.eu
Configuration 4-stroke, vertical, water-cooled diesel engine
Maximum output at crankshaft * 80.9 kW@3200 rpm [110 mhp@3200 rpm]
Displacement 2.0 ltr [122 cu in]
Bore x stroke 84 mm x 90 mm [3.31 in x 3.54 in]
Cylinders 4 in line
Combustion system Direct injection with common rail system
Aspiration Turbocharged with intercooler
Starting system Electric starting 12V - 1.4 kW
Alternator 12V - 125A
Cooling system Fresh water cooling by centrifugal water pump
and rubber impeller sea water pump
Lubrication system Enclosed, forced lubricating system
Direction of rotation [crankshaft] Counterclockwise viewed from flywheel side
Dry weight without gear 229 kg [505 lbs]
Environmental EU: RCD (will comply RCD2 from 2016) BSO II EMC
US: EPA Tier 3
Engine mounting Rubber type flexible mounting
NOTE:
Fuel condition: Density at 15°C = 0.84 g/cm
3
: 1 kW = 1.3596 mhp = 1.3410 HP
* Fuel temperature 40°C at the inlet of the fuel injection pump [ISO 8665: 2006]
Technical data is according to ISO 8665: 2006
DIMENSIONS
4JH110 with KM4A2 marine gear
Rear view Right side view
4 J H110 Common Rail Series
MARINE DIESEL ENGINES
