EN_DS4JH45_1214
www.yanmar.eu
Configuration 4-stroke, vertical, water-cooled diesel engine
Maximum output at crankshaft * 33.1 kW@3000 rpm [45 mhp@3000 rpm]
Displacement 2.19 ltr [134 cu in]
Bore x stroke 88 mm x 90 mm [3.46 in x 3.54 in]
Cylinders 4 in line
Combustion system Direct injection with common rail system
Aspiration Natural aspiration
Starting system Electric starting 12V - 1.4 kW
Alternator 12V - 125A
Cooling system Fresh water cooling by centrifugal water pump
and rubber impeller sea water pump
Lubrication system Enclosed, forced lubricating system
Direction of rotation [crankshaft] Counterclockwise viewed from flywheel side
Dry weight without gear 220 kg [485 lbs]
Environmental EU: RCD (will comply RCD2 from 2016) BSO II EMC
US: EPA Tier 3
Engine mounting Rubber type flexible mounting
NOTE:
Fuel condition: Density at 15°C = 0.84 g/cm
3
: 1 kW = 1.3596 mhp = 1.3410 HP
* Fuel temperature 40°C at the inlet of the fuel injection pump [ISO 8665: 2006]
Technical data is according to ISO 8665: 2006
DIMENSIONS
4JH45 with KM35P marine gear
Rear view Right side view
4JH45 Common Rail Series
MARINE DIESEL ENGINES
Содержание
- Jh45 common rail series 1
- Marine diesel engines 1
- Www yanmar eu 1
- Accessories 2
- B25 standard c35 optional 2
- Instrument panels 2
- Marine gears drive 2
- Optional second alternator 12v 125a or 24v 60a high riser mixing elbow instead of l elbow extension wire harness 3m 5m 10m hot water kit with cocks second station harness and panel c35 panel oil pressure sensor for c35 panel extension saildrive leg 75 mm propeller cone nut kit sd60 nmea 2000 convertor for engine monitory system emergency stop switch 2
- Performance curves 2
- Standard package set of flexible engine mounts exhaust mixing elbow l type v belt safety cover fresh water expansion tank alternator 12v 125a operation manual b25 panel sensors for instrument panel seawaterpump front mounted engine topcover for protection 2
- Www yanmar eu 2
