126
Chapter 6
Appendix
The system specications may dier depending on the derived
models.
For detailed system specications, refer to the product catalogue.
CPU (Optional)
Intel i3/i5/i7 (Core) /Pentium Dual Core /
Celeron Procesor
AMD Dual Core Processor
Main Memory Memory type: DDR3 SODIMM
Main Chipset
(Optional)
Intel HM55
Intel HM65
AMD A50M
Hard Disk Drive 9.5mmH SATA HDD
Graphics (Optional)
Intel HD Graphics (Internal)
Nvidia GeForce GT 315M (External)
Nvidia GeForce GT 520M (External)
Nvidia GeForce GT 315M (Optimus)
Nvidia GeForce GT 520M (Optimus)
AMD Radeon HD 6310 (Internal)
AMD Radeon HD 6320 (Internal)
AMD Radeon HD 6470M (External)
Operating
Environment
Temperature: -5~40°C for storage,
10~32°C when operating
Humidity: 5~90% for storage,
20~80% when operating
AC/DC Rating
(Optional)
Input) 100-240VAC, 50/60Hz,
Output) 19VDC 2.1A, 19VDC 3.16A,
19VDC 4.74A
PC Rating (Optional)
19VDC 2.1A (40W) / 19VDC 3.16A (60W),
19VDC 4.74A (90W)
Optional components may not be provided or dierent •
components may be provided depending on the computer
model.
The system specications are subject to change without •
notice.
The hard disk drive capacity of a computer in which •
Samsung Recovery Solution is installed, is represented as
smaller than the product specication.
The amount of memory that Windows can use may be •
smaller than the actual amount of memory available.
Product Specications
