Smart-UPS C 1000/1500 Va 120/230 Vac Rack-Mount 2U10
System Faults
Feature Reference Guide
1000/1500 120 Vac 1000/1500 230 Vac
P00
Output Overload
P01
Output Short Circuit
P02
Output Over Voltage
P04
Unit Over Temperature
P06
AVR Relay Fault
P13
Inverter Fault
Note: Refer to the “Feature Reference Guide” on page 10 for a detailed description of the front panel buttons and icons.
For more information on System Faults, contact customer support at the APC by Schneider Electric Web site, www.apc.com/
support.
Function Button
Timing
(seconds)
UPS
Status
Description
Power
Power On
0.2 Off
Press the POWER ON/OFF button to turn on the UPS.
The UPS will operate on utility power.
If utility power is not available the UPS will operate on battery power.
Power Off
2On
Press the POWER ON/OFF button to turn off the UPS.
Display
Status Inquiry
0.2 On
Press to verify the status or condition of the UPS. The LCD will illuminate
for 60 seconds.
Power Saving
mode
Continuous
Illumination
2On
The LCD will illuminate and the UPS will beep to confirm Continuous
Illumination mode is activated.
The LCD will extinguish and the UPS will beep to confirm that
Power Saving mode is activated. While in Power Saving mode, the LCD
will illuminate if a button is pressed or an event occurs, then extinguish after
60 seconds of no activity.
Mute
Event Specific
0.2 On
Disable any audible alarms caused by an event.
Enable/Disable
2On
Enable or disable the audible alarms. The Mute icon will illuminate and the
UPS will beep once.
Sensitivity
6Off
The Load Capacity icon will flash to indicate the UPS is in Program mode.
Use the
POWER ON/OFF button to scroll through and select Low, Medium,
and High sensitivity levels. The UPS will beep to confirm the selection.
Refer to “Sensitivity adjustment settings” on page 6 in this manual.
Self-Test
2On
The UPS will automatically run a Self-Test of the internal battery when the
UPS is turned on.
A manual Self-Test can be run at any time while the UPS is operating.
Press and hold the
MUTE button, then press the DISPLAY button for 2
seconds until the system emits a short beep to indicate the UPS has started a
Self-Test.
Event Reset
0.2 On
When the Event screen is visible, press and hold the DISPLAY button, then
press the
POWER ON/OFF button to clear the utility failure event counter.
Fault Reset
2Fault
After a fault has been identified, press the POWER ON/OFF button. The icon
will extinguish and the UPS will go to standby mode.
su0752a
su0752b
