ASRock h61m-vg3 [51/69] Advanced screen
![ASRock h61m-vg3 [51/69] Advanced screen](/views2/1159399/page51/bg33.png)
51
Setting wrong values in this section may cause
the system to malfunction.
3.4 Advanced Screen
In this section, you may set the congurations for the following items: CPU Congu-
ration, North Bridge Conguration, South Bridge Conguration, Storage Congura-
tion, Intel(R) Rapid Start Technology, Intel(R) Smart Connect Technology, ACPI
Conguration and USB Conguration.
