![ASRock b85m pro4 [8/86] Connector](/views2/1159407/page8/bg8.png)
4
English
Storage
•
4 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and “Hot
Plug” functions
•
2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and “Hot
Plug” functions
Connector
•
1 x IR header
•
1 x Print Port header
•
1 x COM port header
•
1 x Chassis Intrusion header
•
1 x TPM header
•
2 x CPU Fan connectors (1 x 4-pin, 1 x 3-pin)
•
2 x Chassis Fan connectors (1 x 4-pin, 1 x 3-pin)
•
1 x Power Fan connector (3-pin)
•
1 x 24 pin ATX power connector
•
1 x 8 pin 12V power connector
•
1 x Front panel audio connector
•
1 x SPDIF Out connector
•
2 x USB 2.0 headers (support 4 USB 2.0 ports)
•
1 x USB 3.0 header (supports 2 USB 3.0 ports)
BIOS
Feature
•
64Mb AMI UEFI Legal BIOS with Multilingual GUI support
•
ACPI 1.1 Compliance Wake Up Events
•
SMBIOS 2.3.1 Support
•
CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
Support
CD
•
Drivers, Utilities, AntiVirus Soware (Trial Version), Cyber-
Link MediaEspresso 6.5 Trial, Google Chrome Browser and
Toolbar, Start8
Hardware
Monitor
•
CPU/Chassis Temperature Sensing
•
CPU/Chassis/Power Fan Tachometer
•
CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-
Adjust by CPU Temperature)
•
CPU/Chassis Fan Multi-Speed Control
•
CASE OPEN detection
