7
English
Z170 Extreme3
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN2)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
6 ATX Power Connector (ATXPWR1)
7 USB 3.0 Header (USB3_7_8)
8 Chassis Fan Connector (CHA_FAN3)
9 SATA3 Connectors (SATA3_0_2)
10 SATA3 Connectors (SATA3_1_3)
11 SATA Express Connectors (SATA_EXP_0_1)
12 Chassis Fan Connector (CHA_FAN2)
13 Power LED and Speaker Header (SPK_PLED1)
14 System Panel Header (PANEL1)
15 SATA and SATA Express Connectors (SATA3_5_4, SATA_EXP2)
16 Clear CMOS Jumper (CLRMOS1)
17 USB 2.0 Header (USB_3_4)
18 USB 2.0 Header (USB_1_2)
19 underbolt AIC Connector (TB1)
20 TPM Header (TPMS1)
21 Front Panel Audio Header (HD_AUDIO1)
22 Chassis Fan Connector (CHA_FAN1)
