61
USB Mouse Power On
Use this item to enable or disable the system to wake from S5 using USB
Mouse.
ACPI HPET table
Use this item to enable or disable ACPI HPET Table. The default value is
[Enabled]. Please set this option to [Enabled] if you plan to use this moth-
erboard to submit Windows
®
Vista
TM
certif cation.
