Asus tuf sabertooth z87 [52/166] Cpu heatsink and fan assembly installation

2-4

Chapter 2: Basic installation

Chapter 2

2.1.3 CPU heatsink and fan assembly installation

Apply the Thermal Interface Material to the

CPU heatsink and CPU before you install

the heatsink and fan, if necessary.

To install the CPU heatsink and fan assembly
