BBE MAX-X2 [7/12] Rear panel
![BBE MAX-X2 [7/12] Rear panel](/views2/1000160/page7/bg7.png)
Max-X2 REAR PANEL
1. AC JACK & AC FUSE HOLDER
Please note that, depending on the main voltage supplied to the unit, the correct fuse type and rating must be
installed.
2. HIGH OUTPUT CONNECTORS:
Connect to your ampliers via these unbalanced 1/4” output jacks.
3. LOW OUTPUT CONNECTORS:
Connect to your ampliers via these unbalanced 1/4” output jacks.
4. STEREO INPUT CONNECTORS:
Connect your L/R stereo input signal to either the XLR or the 1/4” input jacks.
REAR PANEL
2
4
3
1 2 43
– 3 –
