2-11ASUS RS720-E7/RS12; RS720-E7/RS12-E
2CPUConguration
DIMM_A2 DIMM_A1 DIMM_B2 DIMM_B1 DIMM_C2 DIMM_C1 DIMM_D2 DIMM_D1
1 DIMMs
X
2 DIMMs
X
4 DIMMs
X X
8 DIMMs
X X X X
12 DIMMs
X X X X X X
16 DIMMs
X X X X X X X X
2CPUConguration
DIMM_E2 DIMM_E1 DIMM_F2 DIMM_F1 DIMM_G2 DIMM_G1 DIMM_H2 DIMM_H1
1 DIMMs
2 DIMMs
X
4 DIMMs
X X
8 DIMMs
X X X X
12 DIMMs
X X X X X X
16 DIMMs
X X X X X X X X
