ASUS RS720-E7/RS12; RS720-E7/RS12-E 5-19
HighPrecisionEventTimerConguration
High Precision Timer [Enabled]
Allows to enabled/disabled High Precision Event Timer.
Conguration options: [Disabled] [Enabled]
Enables or Disables BIOS ACPI
Auto Conguration.
Intel(R) VT-d [Disabled]
Intel(R) VT-d [Disabled]
Allows you to enable or disable Intel VT-d.
Conguration options: [Enabled] [Disabled]
Intel(R)VTforDirectedI/OConguration
The following item appears only when you set
Intel(R) VT-d
to [Enabled].
Coherency Support [Disabled]
Allows to enable/disable VT-d Engine Coherency support.
Conguration options: [Disabled] [Enabled]
ATS Support [Disabled]
Allows to enable/disable VT-d Engine address translation services (ATS)
support. Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
