5-28 Chapter 4: BIOS setup
Enable/Disable USB 2.0 (EHCI)
Support.
EHCI Controller 1 [Enabled]
EHCI Controller 2 [Enabled]
Rear USB #1 [Enabled]
Rear USB #2 [Enabled]
Onboard USB #3 [Enabled]
Onboard USB #4 [Enabled]
Onboard USB #5 [Enabled]
Onboard USB #6 [Enabled]
Onboard USB #10 [Enabled]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
USBPortsConguration
5.4.10 Trusted Computing
Enables or Disables BIOS
support for security device.
O.S. will not show Security
Device. TCG EFI protocol and
INT1A interface will not be
available.
Conguration
TPM Support [Enabled]
Current Status Information
No Security Device Found
TPM Support [Enabled]
Allows you to enable or disable the TPM support.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.
EHCI Controller 1/2 [Enabled]
Allows to enable or disable USB (EHCI) Support.
Conguration options: [Disabled] [Enabled]
Rear USB #1 and #2 [Enabled]
Allows to enable or disable rear USB #1 and #2.
Conguration options: [Disabled] [Enabled]
Onboard USB #3/#4/#5/#6/#10 [Enabled]
Allows to enable or disable Onboard USB #3 / #4 / #5 / #6 / #10.
Conguration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
