9ASUS Xonar U3
8.2 Main Setting
8.2.1 Sample Rate
The Sample rate determines the number of audio samples per second that the
Digital-to-Analog Converters (DAC) and S/PDIF digital interface will output. The
Xonar U3 audio card can support sample rates up to 48KHz. Even if your setting
differs from the audio source’s sample rate, the Xonar U3 engine will do super high
delity sample-rate-conversion with a double oating-point lter.
No Item Description
1 Sample Rate
The Xonar U3 supports sample rates up to 48KHz.
