28 ASUS Xonar U3

No Item Description

1 Music Mode

This mode is set for Music playback.

2 Movie Mode

This mode is set for DVD Movie playback.

3 GX Mode

DirectSound 3D Game Extensions mode to support EAX and

DirectSound 3D Hardware extensions for lots of DirectX/

DirectSound3D games on Windows Vista.

4 Hi-Fi Mode

This mode is set for Hi-Fidelity playback, where all effects will

be cleared to keep the original digital data and analog output

quality as high as possible.

5 Game Mode

This mode is set for Games.
