vi
(continued on the next page)
TROOPER B85 specications summary
CPU
LGA1150 socket for New 4th Generation Intel
®
Core
TM
i7/ i5/ i3, Pentium
®
and Celeron
®
Processors
Supports 22nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
B85 Express Chipset
Memory
2 x DIMMs, max. 16GB DDR3 1600/1333 MHz, non-ECC, unbuffered
memory modules
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* Due to chipset limitations, memory modules higher than 1600 MHz will run at
1600MHz frequency for better stability.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
VGA
Integrated Graphics Processor - Intel
®
HD Graphics support
Multi-VGA output support: DVI/D-sub port
- Supports DVI-D with max. resolution up to 1920 x1200@60Hz
- Supports D-sub with max. resolution up to 1920 x1200@60Hz
- Supports Intel
®
InTru
TM
3D/Quick Sync Video/Clear Video HD
Technology/Insider
TM
- Supports up to 2 displays simultaneously
- Maximum shared memory of 1GB
Multi-GPU support Supports AMD® Quad-GPU CrossFireX™ Technology
Expansion slots
1 x PCI Express 3.0/2.0 x16 slot (at x16 mode)
1 x PCI Express 2.0 x16 slot [black] (max. at x4 mode, compatible with
PCIe x1 and x4 devices)
1 x PCI Express 2.0 x16 slot [black] (max. at x1 mode, compatible with
PCIe x1 device)
2 x PCI Express 2.0 x1 slots
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS TROOPER B85 motherboard
Cables 2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O Shield
1 x TUF inside sticker
Application DVD Support DVD
Documentation
User manual
Feature manual
TUF Certication card
TUF 5-Year Warranty card (by region)
If any of the above items is damaged or missing, contact your retailer.
