Asus tuf trooper b85 [7/48] Trooper b85 specifications summary
![Asus tuf trooper b85 [7/48] Trooper b85 specifications summary](/views2/1162297/page7/bg7.png)
vii
TROOPER B85 specications summary
Storage
Intel
®
B85 Express Chipset:
- 4 x SATA 6.0Gb/s connectors (black)
- 2 x SATA 3.0Gb/s connectors (beige)
- Supports Intel
®
Rapid Start Technology* and Intel
®
Smart Connect
Technology*
* These functions will work depending on the CPU installed.
LAN
Realtek
®
RTL8111GR Gigabit LAN Controller
Audio Realtek
®
ALC887 8-Channel High Denition Audio CODEC
- Supports Jack-detection, multi-streaming, and Front Panel Jack-retasking
- Separate layer for left and right track, ensuring both sound deliver equal
quality
- LED-lit Audio Shielding ensures precision analog/ digital separation and
greatly reduced multi-lateral interference, with a gorgeous illuminated trace
path.
USB
Intel
®
B85 Express Chipset - supports ASUS USB 3.0 Boost
- 2 x USB 3.0/2.0 ports at mid-board for front panel support
- 2 x USB 3.0/2.0 ports at back panel (blue)
- 8 x USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at the back panel)
Exclusive TUF
features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Radar Core
“TUF ENGINE!” Power Design
- 4+1 Digital Phase Power Design
- TUF Components (10K Ti-Cap, TUF Chokes & MOSFET; certied by
military-standard)
- ASUS DIGI+ Power Control Utility
“Safe & Stable!” Guardian Angel
- TUF LANGuard
- TUF ESD Guards 2
Other special
features
- USB 3.0 Boost featuring speedy USB 3.0 transmission
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- AI Suite 3
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- EZ Update
- Disk Unlocker
- ASUS EZ Flash 2
- Multi-language BIOS
(continued on the next page)
